    Steel Frame Prefab Modular Homes Modern Farmhouse For Tropical Countries

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SU-PH14
    Certification : CE; ISO
    Price : USD180-USD250 per square meter
    Supply Ability : 500 square meter per week
    • Product Details
    • Company Profile

    Steel Frame Prefab Modular Homes Modern Farmhouse For Tropical Countries

    Good Design Steel Frame Granny Villa/Luxury Light Steel Frame Villa/China Prefabricated Villa


    Prefab steel structure with panel is widely used as large factory, warehouse, workshops, storage, stadiums, offices, accommodation and other buildings. Steel structure building with ALC panel is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors.


    Building's PartDescriptionSpecification
    Major StructureMajor StructureSteel FrameHANGANG Chinese Standard,G550-Z275 C-shaped SteelAccording to design requirements
    ConsumablesScrew,bent parts,L parts,etcAccording to design requirements
    RoofDeco LayerFiberglass reinforcement asphalt shingleStandard 3mm thick
    Ceiling InsulationGlass wool blanket100mm thick,18kg/m³
    Structural LayerOriented Strand Board1220*2440*12,waterproof type
    Waterproof LayerWaterproof rollTwo-sided Pressure Sensitive Adbesive SBS Sticky Roll
    CorniceOriented Strand Board1220*2440*12,waterproof type
    PVC cornice closure platewhite
    Outer WallOuter Deco LayerVantilation ShuttersVantilation
    Fiber-cement stack plate3600*210*8
    Filled LayerGlass wool blanket100mm thick,18kg/m³
    Insulating LayerXPS extruded polystyrene boardGrade B1,1200*600*50
    Rough GroudRough groundantiseptic treatment,40*50
    moisture proffing courseLamininating films0.35mm,unidirection
    Structural LayerOriented Strand Board1220*2440*9,
    Interior WallDry AreaPaper double drywall1200*2400*9.5,
    Wet AreaMonolayer cement fiber board1200*2400*10
    FloorFloorOriented Strand Board1220*2440*18,
    Door & WindowEntry DoorSteel Security Doors900*2100
    WindowAluminum Alloy WindowDouble Glass Insulation Window

    CHARACTERISTICS

    1. Excellent seismic performance. The overall structure is firm, light weight and uniform load distribution.
    2, good insulation performance. The multi-layer board is filled with insulation material, and the insulation performance is improved by 65% compared with the brick-concrete construction method.
    3. The construction period is short. The prefabrication of the materials is done at the factory and the installation takes only 30 days and can be carried out all year round.
    4. The overall cost is low.


    Steel Frame Prefab Modular Homes Modern Farmhouse For Tropical CountriesSteel Frame Prefab Modular Homes Modern Farmhouse For Tropical CountriesSteel Frame Prefab Modular Homes Modern Farmhouse For Tropical Countries
