| Item name | Container House |
Top Frame
| Roof surface steel plate | 0.5mm color steel plate (butyl tape) |
| Roof insulation | 100mm glass wool blanket 14kg/m³, double-layer insulation ceiling |
| Top Beam | Section size 160mm, 3.0mm thickness |
Roof corner fitting | High-grade bailing box corner fitting 210mm*150mm*200mm*4.0mm
thickness |
| Roof purlin | C-type steel 100mm*40mm*1.0mm 5pcs + square tube 30mm*30mm*1.0mm 2
pcs |
| Ceiling tile | Factory prefabricated V831 high-quality color steel ceiling tile
0.45mm, matching Z-type parts |
Bottom Frame
| Bottom Main Beam | Section size 160mm, thickness 3.0mm |
| Bottom corner fitting | High-grade bailing box corner fitting 210mm*150mm*160mm*4.0mm
thickness |
| Bottom purlin | Square tube 100mm*50mm*1.2mm*14pcs, high-dense purlin |
Cement fiber board | 1172mm*2800mm*18mm, damp-proof, fireproof, deformation |
| Plastic floor | 1.6mm PVC plastic floor, with resistant and anti-skid layer |
| Bottom insulation | 100mm glass wool blanket 14kg/m³, one-side alluminized paper,
0.45mm color steel sheet (optional) |
Doors & Windows
| Container house specialized security door | 845mm*2050mm color steel sheet 0.6mm thickness |
| Container house specialized windows | 1130mm*1100mm hollow glass 3+6+3 security mesh |
Column and wall
| Column | 210mm*150mm, thickness 3.0mm |
| Insulation wall panel | 75mm glass wool sandwich panel, V1150 type, double side base panel
thickness 0.4mm(Orange peel pattern), 50kg/m³ |
Structure auxiliaries
| Wiring system on the roof | Including one set light line, two sets socket lines, one set
air-conditioner line, one set distribution box including air switch
and one explosion-proof plug |
| Electrical | Premium Brand single open switch*1, five hole socket*4, 16A
air-conditioner socket*1, 24W ceiling light*2 including wires |
| 75mm Gutter | 0.8mm steel panel bending piece, including drain hole |
| Rainpipe | dia. 50mm PVC rainpipe*4, including clips |
| Internal corner edge trim | 0.6mm steel panel bending piece, including punching at the sockets |
Installation accessories
| Container spliced lock set | Hexagon socket screw and steel splice plate, lock on up, down, left
and right respectively |
| Waterproof accessories | Epdm waterproof tape and hosepipe weather proofing sealant |
| Fastener to fix with the ground | Container house special customized aluminum alloy anti-skid plate |
| Column decorative sheet | three-section splicing type decorative buckle gusset plate |
