    2 Floors Prefabricated Light Gauge Steel House Fireproof Fast Assembly

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SU-LV
    Certification : CE; ISO
    Price : USD180-USD250 per square meter
    Supply Ability : 500 square meter per week
    • Product Details
    • Company Profile

    2 Floors Prefabricated Light Gauge Steel House Fireproof Fast Assembly

    2 Floors Light Gauge Steel Frame Prefabricated House Villa


    Design service years: 60 years. This figure is calculated based on conservative theoretical estimation; the actual life time may be even longer. We can design it according to your request .


    Fire resistant rating: 1~4 hours . We can design it according to your request


    Advantages:

    (1). Environment protective, no garbage caused
    (2). Doors, windows and interior partitions can be flexibly fixed
    (3). Beautiful appearance, different colors for the wall and roof.
    (4). Cost saving and transportation convenient
    (5). Anti-rust and normally more than 15 years using life
    (6).Safe and stable, can stand 8 grade earthquake.


    Building's PartDescriptionSpecification
    Major StructureMajor StructureSteel FrameHANGANG Chinese Standard,G550-Z275 C-shaped SteelAccording to design requirements
    ConsumablesScrew,bent parts,L parts,etcAccording to design requirements
    RoofDeco LayerFiberglass reinforcement asphalt shingleStandard 3mm thick
    Ceiling InsulationGlass wool blanket100mm thick,18kg/m³
    Structural LayerOriented Strand Board1220*2440*12,waterproof type
    Waterproof LayerWaterproof rollTwo-sided Pressure Sensitive Adbesive SBS Sticky Roll
    CorniceOriented Strand Board1220*2440*12,waterproof type
    PVC cornice closure platewhite
    Outer WallOuter Deco LayerVantilation ShuttersVantilation
    Fiber-cement stack plate3600*210*8
    Filled LayerGlass wool blanket100mm thick,18kg/m³
    Insulating LayerXPS extruded polystyrene boardGrade B1,1200*600*50
    Rough GroudRough groundantiseptic treatment,40*50
    moisture proffing courseLamininating films0.35mm,unidirection
    Structural LayerOriented Strand Board1220*2440*9,
    Interior WallDry AreaPaper double drywall1200*2400*9.5,
    Wet AreaMonolayer cement fiber board1200*2400*10
    FloorFloorOriented Strand Board1220*2440*18,
    Door & WindowEntry DoorSteel Security Doors900*2100
    WindowAluminum Alloy WindowDouble Glass Insulation Window
