Portable Steel Structure Knockdown Prefab House For Labour Residential Accommodation
| Item Name | Material | Specification | Unit |
| Dimension | | 13.0*8.9*7.023 | m3 |
| column 1 | Q235B | 200*200*6.0mm square tube | T |
| column 2 | Q235B | 100*100*3.0mm square tube | T |
| column 3 | Q235B | 80*80*2.0mm square tube | T |
| canopy beam | Q235B | 80*80*2.0 square tube | T |
| roof frame beam | Q235B | C80*35*15*2+50 square tube | T |
| flooring beam | Q235B | HN298x149x5.5x8mm | T |
| roof purlin | Q235B | C80*35*15*2 | T |
| flooring purlin | Q235B | HN248x124x5.5x8mm | T |
| ring beam | Q235B | 80*80*2 square tube | T |
| free supporting | Q235B | L50*3.0 | T |
| gusset plate | Q235B | | T |
| material loss | Q235B | 5% | T |
| component making | | includes the cutting, welding, painting, etc | T |
| component paint | | coating painting | T |
| roof panel | | L*960*50mm rock wool sandwich panel with 0.5mm color steel sheet (Huaguan brand) | ㎡ |
| external wall panel | | L*950*50mm rock wool sandwich panel with 0.5mm color steel sheet (Huaguan brand) | ㎡ |
| partition wall panel | | L*950*50mm rock wool sandwich panel with 0.426mm color steel sheet (normal brand) | ㎡ |
| sandwich panel cutting charge | | | ㎡ |
| steel decking | | 1000-50-0.8 | ㎡ |
| L shape block materials for the steel decking | | galvanized | m |
| glass wall | | 13000*2400H | ㎡ |
| manual rolling door | | 1600*2400H | ㎡ |
| aluminm sliding windows 1 | | double glazing glass. 1130*1000H*8 pc | ㎡ |
| aluminm sliding windows 2 | | 1130*1000*1 pc | ㎡ |
| aluminm sliding windows 3 | | 1130*1000*2 pc | ㎡ |
| aluminm sliding windows 4 | | 600*600 for toilet | set |
| steel door | | 880*2040*8 pc | set |
| sandwich panel door | | 750*2000*4 pc for toilet | set |
| stair | | with handrail | set |
| flashing materials | | Steel plate bending, self tapping screw, Latin, silica gel, etc | ㎡ |
| galvanized groove | | for fixed the panles | m |
| chemical screws | | M20 | set |
| high strength screw | | M20 | set |
Sussman Modular House (Wuxi)Co.,Ltd
We, Sussman House（Wuxi）Co.,Ltd, is specialized in
building materials of light steel structure, the container house
ect. Since the factory founded 13 years before, it’s always
design and produce various of light gauge house.
Company building area is 15000 square meters, it has a highly
efficient design, manufacturing, sales of high-quality team. The
machine is coving in 30provinces of China and worldwile.
The company always adhere to the "quality first, integrity first,
service fast, continuous innovation" concept. Adoption of new
technologies, development of new products, the application of
advanced scientific management, and strive to make product quality
better and better.
The company sincerely cooperated with the steel, car, the city of
road&bridge construction industry field.
